Analogue Universal Testing Machine

Product Details:

Voltage 120-280 Volt (v)
Material Mild Steel
Application Industrial
Color White & Blue
Product Type Analogue Universal Testing Machine
Machine Weight 5-100 Kilograms (kg)
Share Your Product:

Get a Price/Quote

Request To Call Back Send Inquiry

Analogue Universal Testing Machine Price And Quantity

Minimum Order Quantity 1 Unit

Analogue Universal Testing Machine Product Specifications

Voltage 120-280 Volt (v)
Application Industrial
Machine Weight 5-100 Kilograms (kg)
Material Mild Steel
Color White & Blue
Product Type Analogue Universal Testing Machine

Analogue Universal Testing Machine Trade Information

Payment Terms Telegraphic Transfer (T/T) Cheque
Supply Ability 1 Unit Per Day
Delivery Time 1-2 Week
Main Export Market(s) South America Western Europe Asia Australia North America Eastern Europe Middle East Central America Africa
Main Domestic Market All India

Product Description

Analogue Universal Testing Machine

With our vast industry experience, we are involved in offering a large array of Analogue Universal Testing Machine to our esteemed clients. This machine is made using high grade factor inputs and sophisticated machinery under the supervision of experts as per the international standards. Our offered range of testing machine is well-tested on defined parameters to ensure its flawlessness. Due to precision engineering, optimum quality, reliable functionality and durability, this machine is highly demanded by our clients.

Analogue Cum Computerised Universal Testing Machines Features:

The DC valve is provided which directs oil flow either to analogue or computerized control panel. One can use one system at a time.
Both Analogue & Computerized control panel is provided

Technical Specification For Analogue Cum Computerised Versions

MODEL	TUE-CN-100	TUE-CN-200	TUE-CN-400	TUE-CN-600	TUE-CN-1000	TUE-CN-2000
Measuring Capacity (kN)	100	200	400	600	1000	2000
Analogue System
Range (kN)	0 - 100	0 - 200	0 - 400	0 - 600	0 - 1000	0 - 2000
Least Count (kN)	0.2	0.4	0.8	1	2	4
Range (kN)	0 - 50	0 - 100	0 - 200	0 - 300	0 - 500	0 - 1000
Least Count (kN)	0.1	0.2	0.4	0.5	1	2
Range (kN)	0 - 25	0 - 50	0 - 100	0 - 120	0 - 250	0 - 500
Least Count (kN)	0.05	0.1	0.2	0.2	0.5	1
Range (kN)	0 - 10	0 - 20	0 - 40	0 - 60	0 - 100	0 - 200
Least Count (kN)	0.02	0.04	0.08	0.1	0.2	0.4
Computerised System
Measuring Range (kN)	0 - 100	0 - 200	0 - 400	0 - 600	0 - 1000	0 - 2000
Least Count (kN)	0.01	0.02	0.04	0.06	0.1	0.2
Load Range in kN with accuracy of measurement +1%	2 to 100	4 to 200	8 to 400	12 to 600	20 to 1000	40 to 2000
Resolution of Piston Movement (mm)	0.1	0.1	0.1	0.1	0.1	0.1
Over all dimensions approx. (mm)	1950 x 800 x 1850	2000 x 800 x 1900	2100 x 800 x 2060	2200 x 800 x 2400	2350 x 800 x 2700	3000 x 800 x 3600
Weight approx. (kg.)	1300	1400	2200	3200	4200	8600

Common Specification For All Versions

MODEL	TUE-CN-100	TUE-CN-200	TUE-CN-400	TUE-CN-600	TUE-CN-1000	TUE-CN-2000
Measuring Capacity (kN)	100	200	400	600	1000	2000
Max. Tensile Clearance at fully decended piston position(mm)	50 - 700	50 - 700	50 - 700	50 - 800	50 - 850	50 - 900
Max. Clearance for Compression Test (mm)	0 - 700	0 - 700	0 - 700	0 - 800	0 - 850	0 - 900
Distance between columns (mm)	450	500	500	600	750	850
Piston Stroke (mm)	150	200	200	250	250	300
Max. straining speed at no load (mm/min)	300	150	150	100	80	45
Power Supply	3 phase 415V 50Hz AC
Total H.P.	1.5	1.5	2.5	2.5	4.0	6.5

Standard Accessories For All Versions

Model	TUE-CN-100	TUE-CN-200	TUE-CN-400	TUE-CN-600	TUE-CN-1000	TUE-CN-2000
Pair for compression plate dia (mm)	120	120	120	120	160	220
Tension Test Jaws
For Round Specimen dia (mm)	10 - 20	10-20	10 - 25	10 - 25	10 - 30	20 - 40
For Round Specimen dia (mm)	20 - 30	20 - 30	25 - 40	25 - 40	30 - 50	40 - 60
For Round Specimen dia (mm)	-	-	-	40 - 55	50 - 70	60 - 80
For Flat Specimen Thickness(mm)	0 - 10	0 - 10	0 - 15	0 - 15	0 - 22	0 - 22
For Flat Specimen Thickness(mm)	10 - 20	10 - 20	15 - 30	15 - 30	22 - 44	22 - 45
For Flat Specimen Thickness (mm)	-	-	-	-	44 - 65	45 - 70
Max. width of Flat Specimen(mm)	50	50	65	70	70	90
Transverse Test
Adjustable Roller Support of width (mm)	150	150	150	160	160	200
Diameter(mm)	30	30	30	50	50	70
With Max. adjustable clearance (mm)	450	500	500	600	800	900
Punch tops of radius (mm)	6	6	10	16	16	30
Punch tops of radius(mm)	12	12	16	22	22	40

Enter Buying Requirement Details

+ Add Attachment

Email Id

Mobile number

Please Wait...

Other Products in 'Universal Testing Machine' category

Electro Mechanical Servo Control Universal Testing Machine (Double Column) Price : 1 INR/Number Minimum Order Quantity : 1 Machine Weight : 160 to 800 Kilograms (kg) Voltage : AC220 Volt (v) Power : 50Hz Volt (v)

Send Inquiry

Digital Electro Mechanical Universal Testing Machine (single Ball Screw) Price : 1 INR/Number Minimum Order Quantity : 1 Machine Weight : 90 Kilograms (kg) Voltage : AC220 Volt (v) Dimension (L*W*H) : 425x400x1315 Millimeter (mm) Power : AC2205%, 5060Hz Volt (v)
